Product Introduction
The YS-SL-6045B Semi-Automatic Shrink Wrapping Machine is a pneumatic L-bar sealing machine designed for shrink film packaging applications. The machine utilizes a bottom sealing system and works together with a shrink tunnel to create tight, secure, and professional packaging for a wide range of products.
Suitable for food, beverages, cosmetics, pharmaceuticals, electronics, stationery, and daily consumer goods, the YS-SL-6045B offers stable operation, easy maintenance, and flexible packaging capabilities for medium-volume production environments.
| Item | Specification |
|---|---|
| Model | YS-SL-6045B |
| Machine Type | Semi-Automatic Shrink Wrapping Machine (Pneumatic) |
| Power Supply | 1P AC220V / 50Hz |
| Power Consumption | 1.0 kW |
| Air Pressure | 0.6 – 0.8 MPa |
| Working Table Height | 780 mm |
| Sealing System | Bottom Sealing |
| Packaging Speed | 8 – 15 pcs/min |
| Film Roll Size | Φ250 × W640 mm |
| Maximum Sealing Size | 580 × 430 mm |
| Maximum Product Length | ≤530 mm |
| Maximum Product Width | ≤380 mm |
| Maximum Product Height | ≤150 mm |
| Packaging Limitation | W + H ≤460 mm |
| Machine Dimensions | 1510 × 830 mm |
| Matching Shrink Tunnel | YS-ST-5025 |
| Operation Mode | Semi-Automatic |
