Product Introduction
The CF-25TB One-Click Robot Carton Erector is a fully automatic carton forming solution designed for high-speed packaging lines. Equipped with an intelligent robotic handling system, the machine automatically picks, opens, forms, and seals cartons with high precision and efficiency.
Suitable for food, beverage, pharmaceutical, daily chemical, e-commerce, and logistics industries, the CF-25TB significantly reduces labor requirements while ensuring stable and continuous carton erecting performance.
| Item | Specification |
|---|---|
| Model | CF-25TB |
| Machine Type | One-Click Robot Carton Erector |
| Power Supply | 1P / 220V / 50Hz |
| Power Consumption | 4.6 kW |
| Air Pressure | 0.6 – 0.8 MPa |
| Machine Dimensions | 2710 × 2480 × 2180 mm |
| Machine Weight | 1000 kg |
| Tape Width | 48 – 72 mm |
| Production Speed | 20 – 30 Boxes/min |
| Suitable Cartons | Standard Corrugated Cartons |
| Operation Mode | Fully Automatic |
